The Cutter Suction Dredger Made Of Alloy Cast Iron Has Stronger
Wear Resistance
1. About Leader Dredger Company:
Reliable and efficient
Leader Dredger is known for its solid structure, reliable operation
and outstanding performance. To date, Leader Dredger has provided
more than 100 dredgers worldwide. With rich experience in design
and production, we can provide you with ideal dredging equipment
Service support
Leader Dredger can provide professional maintenance support,
equipment training programs, and dredging consulting services.
And manual guidance and commissioning of equipment
3. Why Choose Leader Dredger Cutter Suction Dredger
1. World-class design and quality.
With our decades of experience in this field, our engineering team
is fully capable of designing the best dredger according to the
specific conditions and requirements of customers. Strictly abide
by the highest national quality standards and comprehensively run
tests before shipment, so that each of our dredgers have
world-class quality.
2. Cheap price.
Compared with European and American suppliers, it can save 50% of
the cost, and the quality is the same.
3. Engineers can be used for overseas installation and training.
Our engineers will go to the customer's work site to help dredge
installation and training staff.
4. Design
From inspecting the customer's individual situation to designing,
manufacturing, testing, transporting, installing and training
customer workers, from start to finish, one-stop, one-stop
operation.
5. Global transportation.
We ship to places around the world where our products are needed.
4. Leader Dredger Cutter Suction Dredger Feature:
1. Inherent stability, can be used in semi-protected water.
2. Very suitable for first-time owners and operators-easy to train
and operate.
3. Relatively low initial investment, long-term use.
4. Easy to transport on the highway by truck.
5. Ideal choice for ponds, lakes, rivers and self-managed
government dredging programs
5. Leader Dredger LD4500 Sand Cutter Suction Dredger Service:
1. We will provide 12 months of quality assurance of diesel engine,
generator, gear box, hydraulic system and control system free of
charge
2. 24-hour after-sales service.
3. Engineers can board the ship for installation and train
operators
4. We have experienced and qualified technicians and engineers who
can design reasonable and feasible solutions according to customer
requirements and working conditions
6. LEADER DREDGER LD4500IP TECHNICAL SPECIFICATIONS
| Dredging Features |
| Standard dredging depth(m) | 15m |
| capacity(m/h) | 4500m³/h |
| Solid capacity(approx) | 900m³/h |
| Dredging pump mode | 550/500mm(22"/20") |
| |
| Principal characteristics |
| Overall length(m) | 37m |
| Breadth(m) | 7.6m |
| Draught(m) | 1.6m |
| Discharge distance(m) | 1500m |
| Total dry weight approx(MT) | 185MT |
| Ladder length | 21m |
| |
| Dredge pump: Australia technology Pump |
| By alloy cast iron material for better abrasion resistance,
abrasive, hardness, more than68HRC. Bigger working capacity, more
efficiency, driven through gearbox. |
| Maximum mixture capacity(m/h) | 4500m³/h |
| Solid capacity(approx) | 900m³/h |
| |
| Engine |
| Main diesel engine(Cummins) | Cummins KTA38 895KW CAT3512C 955KW |
| Auxlary engine | Cummins NT8500 298KW CAT C9.3 325KW |
| Total fuel consumption | ≤167kg/hr, ≤59.6kg/hr |
| Extra emergency generator set | 30kw(40Hp) |
7. Leader Dredger Cutter Suction Dredger Customer
8. About Leader Dredger cutter suction dredger dredging pump
The design of the dredge pump allows it to work in the harshest
environment. Dredging pumps and mining pumps are suitable for
pumping and handling all mud, mud, sand, gravel, rock and debris.
The dredging yard has been constantly optimizing the hydraulic
design, so that the dredging pump and mining pump have the highest
efficiency, the best wear performance, the highest reliability and
a long service life.
The bearing seat provided by the dredging yard is designed to
withstand all the forces of the dredging pump and impeller. The
bearing seat is designed and manufactured to resist vibration,
thermal vibration and shock caused by sudden impeller impact and
load. Shafts, bases, bearings and bearing seats are made from
first-class materials and suppliers to ensure the highest
reliability and efficiency.
9. Production time:
Each series of Leader Dredger dredgers will have one in stock,
which is convenient for fast delivery.
But when the construction environment is complex and custom
dredgers are required, we usually need 1 to 3 months to produce.
Leader Dredger cutter suciton dredger is portable and can be
transported and disassembled by road, rail or sea and land.
10. Delivery:
Carried by trucks to the loading seaport, and then by bulk vessels
to the destination seaport.
